LHS2-1400
-
Its canopy allow enough access to do maintenance,which is lockable. Support leg high strengh. 4 telescoping outriggers and leveling jacks. Earth leakage protection system. Residual current device protection.
-
Features Description：
-
Powerful hydraulic lifting system，9 stages mast up can lift to 9m by one-button
-
High strength stainless steel pull rope
-
High-efficiency LED light, AC 230V/240V and DC 48V optional
-
Heavy-duty design, top lifting hole and bottom forklift port.
-
Multi-protected spray canopy with independent lockable access door
-
Residual current device protection (RCD), individual breaker switch for each lamp assembly
-
Fully-enclosed chassis fuel tank meets continuous 50h operation
-
Mute processing, noise level 63dB @ 63m (A)
-
Genuine Kubota engine to meet EPA Tier 4 emission standards
-
German AI-KO trailer, speed ≤65km/h
-
Brakes and parking brakes, brake taillights and turn signals
-
4 manual support legs which make it more stable
-
Technical Parameters:
-
Standard data（AC）
-
Series
LHS2
Model
MLT4KME-1400LHS2
Rated Power
2.8kW
3.3kW
Type of lights
LED 4*360w
Luminous efficiency
A*54000lms
Lamps Rotation
Allow manual rotation of 75 °
Receive size
278A*1150*2535mm
Mast Heigth
Fully Extended 9000mm
Weight (net)
1100 kg
Fuel Tank Capacity
100L,Juel Tank Operating 50 h
Engine Brand
Kubota
Frequency (Hz)
50
60
Engine Model
Z482
Z482 EPA Tier4
Alternator Model
LT75
-
Optional data（AC）
-
Series
LHS2
Model
MLT4KSC - 1400DLHS2
Rated Power
2.8 kW
Type of lights
LED 4*360w
luminous efficiency
4*54000lms
Fuel Tank Capacity
100L,FuelTank Operating 50 h
Engine Brand
Kubota
Engine Model
Z482
Alternator Model
FB 4-48/100
